Key Features
- Dust-proof enclosed type motor for durability
- Electrically operated shutter prevents outside air backflow
- Complies with waterproof standard IPX4 (outdoor)
- Low noise and stable airflow performance
- Suitable for bathrooms, kitchens, offices, and storage rooms
- Meets international safety standards IEC 60335-2-80 & IEC 60335-1
- Meets international EMC standards IEC 55014-1, IEC 55014-2, IEC 61000-3-2, IEC 61000-3-3
Technical Specifications
| Model |
Voltage (V) |
Frequency (Hz) |
Power (W) |
Speed (r/min) |
Noise (dB) |
Air Volume (m³/h) |
| VF-F12 |
220–240 |
50 |
45 |
1160 |
44 |
1080 |
Dimensions
| Model |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
Installation ≥D'' (mm) |
E (mm) |
| VF-F12 |
390 × 390 |
95 |
103 |
317 |
≥520 |
Φ320 |
Certifications
- CE Certified
- RoHS Compliant
- IPX4 Waterproof Rating
- IEC 60335-2-80:2015
- IEC 60335-1
- EN IEC 55014-1:2021
- EN IEC 55014-2:2020
- IEC 61000-3-2 & IEC 61000-3-3
Application Areas
- Bathrooms & toilets
- Kitchens
- Utility rooms
- Shops & small commercial spaces
- General air exchange installations
